PLB HDPE TELECOM Ducts

ADWANTAGES

Manufactured from virgin raw Material.
Suitable for working pressure up to 7.0 bar.
Available sizes 32,40,50,63 and 110mm OD.
Available in coils of 100-1,000 Meter long
Manufactured in Two Layers in which inner layer being lubricant material resulting Very low friction
Optical fiber cables can be inserted by blowing technology for lengths up to 1km at a stretch
Available in eight colours for easy identification. (Red, Orange, Green, Blue, Yellow, Violet, Brown and Gray).
Easy repair in the event of damage.
No outer painting required.
Very low maintenance cost.
Can be joined with duct couplers. The can be protected with end caps
. Outstanding ability to withstand Rapid Crack propagation (RCP).
High resistance to Crack Growth
Ducts can be supplied with tracer wire for underground tracability
Ducts can be supplied with pre-inserted rope for smaller length of coils in order to avoid blowing machines.
ACCESSORIES:Duct couplers, End Caps, End Plugs, Cable Sealings

OFC CABLE DUCT SPECIFICATIONS

	32 mm/26 mm	40 mm/33 mm	50 mm/42 mm	63 mm/50 mm	110 mm/80 mm
Outside Diameter	32mm +0.3 -0.0	40mm +0.4 -0.0	50mm +0.4 -0.0	63mm +0.6 -0.0	110mm +1.0 -0.0
Wall Thickness	3.0mm + 0.2mm	3.5mm + 0.2mm	4.0mm + 0.3mm	6.5mm + 0.4mm	15.0mm + 0.6mm
Thickness of Inner Layer (mm)	0.24-0.36	0.28-0.42	0.32-0.48	0.36-0.54	0.56-0.84
Standard Length (mtrs)	1000+ 100	1000+ 100	1000+ 100	500+ 50	100+ 10
Max. OD of the cable that can be inserted Blowing Technique	12 mm	16 mm	21 mm	25 mm 144 Fibres	40 mm 576 Fibres

VPL POLETHYLENE PIPES

HDPE PIPE

Pipes made from Polyethylene (PE) is a cost-effective answer for a number of piping problems in Metropolitan, Municipal, Industrial, Underwater, Mining, Landfill, Gas extraction, Cable duct and agricultural applications. It has been tested and proven effective for underground, above ground, surface, under water as well as floating pipe applications. Polyethylene pipes both High Density (HDPE) and Medium Density (MDPE) can carry potable water, wastewater, slurries, chemicals, hazardous wastes, cables and compressed gases as well as oils. Polyethylene pipes have a long and successful service experience to the gas, oil, mining and water utility industries. PE pipes have the lowest repair frequency per kilometer of pipe per year compared with all other pipe materials used for urban water and gas distribution. VPL PE pipes are strong, durable and cost-effective and long lasting. VPL PE pipes will meet all requirements as per relevant standards. VPL Polyethylene pipes systems are solution for Potable Water Supply, Irrigation and Bore-Well applications. HDPE pipes are manufactured from virgin raw material on the state of the artmanufacturing facilities. The plant follows stringent quality inspection and testing of inwards raw material, processing and post production. It has fully equipped with Quality Control laboratory managed by qualified personnel. The pipes and fitting are offered in PE 63, PE80 and PE100 grades. VPL HDPE potable water, sewer and industrial pipes are manufactured for use in the municipal & industrial markets.

HDPE SEWERAGE PIPES

VPL HDPE potable water, sewer and industrial pipes are manufactured for use in the municipal & industrial markets. VPL HDPE Pipes are WRAS certified for Drinking Water Applications. VPL HDPE potable water pipe designed for use in the municipal and industrial markets provides and monolithic, corrosion and leak free piping system for transporting potable water and other fluids for industrial applications. HDPE pipe is an excellent choice due to its proven track record of providing longevity and reliability in fluid piping systems. With multiple manufacturing locations, the end user is assured of receiving superior products combined with maximum service. VPL HDPE pipes to these markets are quickly being adopted as the better performing material of choice due to its improved properties compared to conventional piping materials like PVC or ductile iron. VPL services this important market because HDPE pipe provides a leak free reliable water system that protects our precious water resources, especially in those arid regions where water is scarce.

FEATURES AND SPECIFICATIONS

RANGE Ø63 to 400m
Pressure rating 2.5 to 16 kgf/cm²
Also available with tracer for easy detection.
STANDARDS IS 14333.
LENGTH Available in straight
lengths of 6/12m-for all sizes & in
coils uptO 125mm OD size.

APPLICATIONS!

Sewerage.
Effluent Conveyance & Waste
Disposal Line
Lining of Existing Sewerage lines.
Chemical Conveyance
Dreger Pipes
Ash Slurry Conveyance
Mining

ISO CERTIFICATION

We are certified to ISO [ISO 4427-1, 2:2019] standards, ensuring compliance with internationally recognized quality management systems. Our facility is approved by Crown Certification Testing Corporation Ltd with A++ Certificate. Which is amendation for Jal Jivan Mission as well as Amrut 2.0 projects. We are also certified and approved by CIPET (Central Institute of Petrocamicals Engineering and Technology) which is a leading facility of plastic based products in Asia. IS: 4984:2016
